Multispectral Electro-Optic Anti Drone PTZ Camera

The SOAR810 is a compact multi-sensor stabilized anti drone PTZ camera platform designed for professional surveillance, mobile monitoring, and long range target tracking in demanding environments.

The system supports modular configurations with high resolution visible cameras, thermal imaging sensors for day-night operation and laser illuminator modules, enabling reliable detection and identification under complex lighting and weather conditions.

It serves as a unified multi-sensor platform that combines multiple sensing technologies within a single integrated system.

Built on an integrated single IP intelligent encoding architecture, the platform simplifies network deployment and multi-sensor management while enabling synchronized video and data output.

Built-in intelligent analytics further support automatic detection and tracking of fire, vehicles, vessels, human targets, and other moving objects, improving operational efficiency in real time security scenarios.

Open AI architecture with third-party algorithm support and continuous model upgrade capability.

Featuring an integrated T-type housing and reinforced structural design, the system delivers high mechanical stability and strong wind-resistance performance for vehicle-mounted and marine surveillance use.

Its rapid-mount architecture allows quick installation, repositioning, and field servicing without complex procedures.

The optional dual-axis gyro-stabilization module actively compensates for vibration and platform motion to ensure stable, clear video output in harsh and high-mobility operating conditions.

KEY FEATURES   Click Icon to know more...

Visible Light (Daylight):  Equipped with a high-resolution camera supporting up to 4MP resolution. The continuous optical zoom lens ranges from 6.6 to 264mm, providing an ultra-long detection range for detailed identification.  Optional lens up to 92x optical zoom （6.1~561mm）

LWIR Thermal (Uncooled): Choose between 640x512 or 1280x1024 resolution cores with a large-aperture lens up to 100mm, ideal for detecting heat signatures through obscurants.

MWIR Thermal (Cooled - Optional): For premium long-range performance, an optional cooled MWIR imager with 18~275mm continuous zoom offers superior thermal sensitivity and faster frame rates.

Integrated Laser Rangefinder (LRF): Built-in LRF capable of measuring distances up to 6 kilometers, providing precise geo-location data for targets of interest.

Optional laser illuminator up to 500 meters.

Advanced Motor Drive: Powered by DC brushless motors, the system achieves rapid pan/tilt speeds of up to 180° (PAN)  120° (Tilt)second, ensuring it never loses track of fast-moving targets.

Ultra-Precise Positioning: Despite its high speed, the system maintains a positioning accuracy of 0.005°, allowing for precise positioning to go to target position.

2-Axis Gyro Stabilization: The integrated stabilization system actively cancels out external vibrations caused by vehicle motion, maritime waves, or wind.

This ensures the video feed remains steady and the target stays locked, drastically reducing operator fatigue during mobile operations.

 The system features an embedded AI processor that performs real-time target detection without the need for a separate server.

Comprehensive Target Library: Trained to automatically detect, recognize, and track a wide variety of objects, including:

Ground/Maritime: Vehicles, Motorcycles/Bicycles, People, Boats.

Security Threats: Fire/Smoke detection (critical for early wildfire warning).
